| Serial number | Project | Parameters |
| 1 | Chassis Type | QL10503HAR1Y |
| 2 | Engine Type | 4JB1CN |
| 3 | Power | 98HP |
| 4 | Chassis wheelbase (mm) | 3360 |
| 5 | Leg Form | H before V after |
| 6 | Footage (mm) | 3600X3815★ |
| 7 | Platform rated load (Kg) | 200 |
| 8 | Maximum operating height (M) | 16 |
| 9 | Maximum operating range (M) | 9.1★ |
| 10 | turntable turning angle (º) | 360º continuous rotation |
| 11 | Platform turning angle (º)) | 90º left and right |
| 12 | Dimensions (mm) | 7750X2000X3150(2950)★ |
| 13 | Maximum speed (Km/h) | 100 |
| 14 | Number of passengers | 2 |
 |
 |
 |
 |
1.Front H-Type supporting leg and rear V-type supporting leg, two section Horizontal Leg, large outrigger span, good stability, the outriggers could be operate separately, it adaptable.The supporting legs can be operated at the same time or alone, in the frame on both sides. To adapt variety of working conditions
|
 |
3.Double amplitude oil cylinder, arms landing and gyration more stable 4.The left and right slewing platform adopts the imported closed swing cylinder, which is flexible, convenient, safe and reliable. |
 |
5.The platform has real-time display of load and weight and overload alarm function 6.With wind speed inspection and alarm function |
 |
|
 |
|
 |
|
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
